Powtran PI9000 series User Manual

Chapter 5 Function parameter
87
d0.27
Master frequency setting
display
0.01Hz
Frequency
set by F0.03 master frequency setting source
d0.28
Auxiliary frequency
setting display
0.01Hz
Frequency
set by F0.04 auxiliary frequency setting source
d0.31
Synchro rotor position
0.0°
Current position angle of synchronous motor rotor
d0.29
Command torque (%)
0.1%
Display the set target torque under torque control mode
d0.32
Resolver position
-
Rotor position when rotary transformer is used as a speed feedback
d0.33
ABZ position
0
Displays AB phase pulse count of the current ABZ or UVW encoder
d0.34
Z signal counter
Displays Z phase pulse count of the current ABZ or UVW encoder
d0.35
Inverter status
Displays inverter running status information
Data definition format is as follows:
d0.35
Bit0
0: stop; 1: forward; 2: reverse
Bit1
Bit2
0: constant; 1: acceleration; 2:
deceleration
Bit3
Bit4
0: bus voltage normal; 1: undervoltage
d0.36
Inverter type
-
1:G type: Suitable for constant torque load
2:F type: Suitable for variable torque load (fans, pumps load)
d0.37
AI1 voltage before correction
0.01V
d0.38
AI2 voltage before correction
0.01V
d0.39
Panel potentiometer voltage before correction
0.01V
d0.40
Reserve
d0.41
motor temperature inspection function
3
0℃
Motor temperature sensor signal，need connect to control board J16 terminal，connect
J15 to PT100.
Note: “Superscript
3
”means software version of C3.00 and above with MCU keyboard
have such function.
5-2-2.Basic function group: F0.00-F0.27
Code
Parameter name
Setting range
Factory
setting
Chang
e
Limit
