Powtran PI9000 series User Manual

Chapter 10 Options
216
19
OCL-
0490-
EISH-
E14U
380
220
490
36.6
0.50%
0.014
243/113/12*20
20
OCL-
0530-
EISH-
E13U
380
240
530
36.6
0.50%
0.013
243/113/12*20
21
OCL-
0600-
EISH-
E12U
380
280
600
43.5
0.50%
0.012
243/128/12*20
22
OCL-
0660-
EISH-
E4U0
380
300
660
44
0.50%
0.011
243/128/12*20
23
OCL-
0800-
EISH-
E5U0
380
380
800
60.8
0.50%
0.0087
260/175/12*20
24
OCL-
1000-
EISH-
E4U0
380
450
1000
61.5
0.50%
0.007
260/175/12*20
25
OCL-
1200-
EISH-
E4U0
380
550
1200
89
0.50%
0.0058
275/175/12*20
26
OCL-
1600-
EISH-
E3U0
380
630
1600
92
0.50%
0.0043
275/175/12*20
10-12-2.Output AC choke(690V)
No.
Model
Voltage(V)
Power(KW)
Rated
Current(A)
Net
weight(kg)
Voltage
drop(V)
Inductanc
e(mH)
Installation
size
D1/W1/A*B(
mm)
1
OCL-
005
690
1.5
5
2.00%
2
OCL-
007
690
2.2
7
2.00%
3
OCL-
0010
690
4.0
10
2.00%
4
OCL-
0015
690
5.5
15
2.00%
5
OCL-
0020
690
7.5
20
2.00%
