Three-phase AC power
Please use the power supply meeting
the specifications of the inverter.
Molded case circuit breaker
(MCCB) or earth leakage circuit
breaker (ELCB)
When the power is on, the inverter will
receive a great impact on current, the
proper selection of breaker is very
important.
Input side
Noise filter
Output side
Noise filter
Braking resistor
(optional)
Braking unit
DCreactor
To prevent electric
shock, the motor and
the inverter must be
well grounded
Connect
to ground
AC output reactor
Motor
Connect to
ground
AC contactor
AC Input reactor
