Powtran PI9000 series User Manual

Chapter 7 Troubleshooting
189
No.
Fault ID
Failure type
Possible causes
Solutions
19
Err.19
Motor
parameter auto
tunning fault
1.the motor parameters was
not set according to the
nameplate
2.the identification process of
parameter is timeout
1.correctly set motor
parameter according to the
nameplate
2.check the lead wire from
the inverter to the motor
20
Err.20
Disk code fault
1.the encoder is damaged
2.PG card is abnormal
3.the encoder model does not
match
4.the encoder connection has
error
1.replace the encoder
2.replace the PG card
3.correctly set the encoder
model according to the
Actual conditions
4.eliminate the line fault
21
Err.21
EEPROM read
and write fault
EEPROM chip is damaged
Replace the main control
panel
22
Err.22
Inverter
hardware fault
1.overvoltage
2.overcurrent
1.eliminate overvoltage
fault
2.eliminate overcurrent
fault
23
Err.23
Short-circuit to
ground fault
Motor short to ground
Replace the cable or motor
26
Err.26
Cumulative
running time
arrival fault
Cumulative running time
arrival fault
Clear history information
by using initialization
function parameters
27
Err.27
Custom fault 1
Input custom fault 1 signal
through the multi-function
terminal DI
Reset run
28
Err.28
Custom fault 2
Input custom fault 2 signal
through the multi-function
terminal DI
Reset run
29
Err.29
Total power-on
time arrival
fault
Total power-on time reaches
the set value
Clear history information
by using initialization
function parameters
30
Err.30
Load drop fault
The inverter running current is
less than F8.31
Confirm whether the load
is removed or not or the
settings for
parameter(F8.31, F8.32)
accord with the Actual
operating conditions
31
Err.31
PID feedback
loss when
running fault
PID feedback is less than the
set value of E2.11
Check PID feedback
signal or set E2.11 to an
appropriate value
40
Err.40
Quick current
limiting
fault
1.whether the load is too large
1.reduce the load and
