Powtran PI9000 series User Manual

Appendix I
230
100 B
AI2 voltage
100C
Reserve
100D
Count value input
100 E
Length value input
100 F
Load speed
1010
PID setting
1011
PID feedback
1012
PLC step
1013
High-speed pulse input frequency, unit: 0.01kHz
1014
Feedback speed, unit:0.1Hz
1015
Remaining run time
1016
AI1 voltage before correction
1017
AI2 voltage before correction
1018
Reserve
1019
Linear speed
101 A
Current power-on time
101 B
Current run time
101C
High-speed pulse input frequency, unit: 1Hz
101D
Communication set value
101 E
Actual feedback speed
101 F
Master frequency display
1020
Auxiliary frequency display
Note:
There is two ways to modify the settings frequencies through communication
mode:
The first: Set F0.03 (main frequency source setting) as 0/1 (keyboard set
frequency), and then modify the settings frequency by modifying F0.01 (keyboard
set frequency). Communication mapping address of F0.01 is 0xF001 (Only need to
change the RAM communication mapping address to 0x0001).
The second :Set F0.03 (main frequency source setting) as 9 (Remote
communication set), and then modify the settings frequency by modifying
(Communication settings). , mailing address of this parameter is 0x1000.the
communication set value is the percentage of the relative value, 10000 corresponds
to 100.00%, -10000 corresponds to -100.00%. For frequency dimension data, it is
the percentage of the maximum frequency (F0.19); for torque dimension data, the
percentage is F5.08 (torque upper limit digital setting).
Control command is input to the inverter: (write only)
