Powtran PI9000 series User Manual

Chapter 5 Function parameter
72
No.
Code
Parameter name
Setting range
Factory
setting
Change
Reference
page
387.
E2.02
PID
feedback source
0 to 8
0
☆
161
388.
E2.03
PID action direction
0:
positive
1: negative
0
☆
162
389.
E2.04
PID setting feedback
range
0 to 65535
1000
☆
162
390.
E2.05
PID inversion cutoff
frequency
0．00 to
F0.19(maximum
frequency)
0.00Hz
☆
162
391.
E2.06
PID deviation limit
0.0% to 100.0%
0%
☆
162
392.
E2.07
PID differential
limiting
0.00% to 100.00%
0.10%
☆
162
393.
E2.08
PID reference change
time
0.00s to 650.00s
0.00s
☆
162
394.
E2.09
PID feedback filter
time
0.00s to 60.00s
0.00s
☆
162
395.
E2.10
PID output filter time
0.00s to 60.00s
0.00s
☆
162
396.
E2.11
PID feedback loss
detection value
0.0%:
not judged
feedback loss
0.1% to 100.0%
0 . 0%
☆
163
397.
E2.12
PID feedback loss
detection time
0.0s to 20.0s
0 . 0s
☆
163
398.
E2.13
Proportional gain
KP1
0.0 to 200.0
80.0
☆
163
399.
E2.14
Integration time Ti1
0.01s to 10.00s
0.50s
☆
163
400.
E2.15
Differential time Td1
0.00s to 10.000s
0.000s
☆
163
401.
E2.16
Proportional gain
KP2
0.0 to 200.0
20.0
☆
163
402.
E2.17
Integration time Ti2
0.01s to 10.00s
2.00s
☆
163
403.
E2.18
Differential time Td2
0.00 to 10.000
0.000s
☆
163
