Printronix S828 - Command Function Sets

ProgrammerManual PTX‐S828
Chapter5IPDSProgrammingInformation 118 260071‐001A
Command Hex Code Description
LPP D66D Logical Page Position
WBCC D680 Write Bar Code Control
WBC D681 Write Bar Code
WGC D684 Write Graphics Control
WG D685 Write Graphics
WIC D63D Write Image Control
WI D64D Write Image
WT D62D Write Text
BO D6DF Begin Overlay
DO D6EF Deactivate Overlay
IO D67D Include Overlay
BPS D65F Begin Page Segment
DPS D66F Deactivate Page Segment
IPS D67F Include Page Segment
LE D61D Load Equivalence
LFE D63F Load Font Equivalence
DF D64F Deactivate Font
END D65D End
Command Function Sets
Function sets divide the printer commands into various categories. Each function set provides all the
necessary controls for its functional area. These function sets are:
● Device Control function set
● Text function set
● Image function set
● Graphics function set
● Bar Code function set
● Overlay function set
● Page Segment function set
● Loaded Font function set.
Device Control Function Set Commands
The Device Control function set contains the commands the printer uses to set up the page, communicate
device controls, and manage the Acknowledge protocol. The following commands are the device control
function set:
Command Hex Code Description
NOP D603 No Operation
STM D6E4 Sense Type and Model
SHS D697 Set Home State
ACK D6FF Acknowledge Reply
LFE D63F Load Font Equivalence
LCC D69F Load Copy Control
