ProgrammerManual PTX‐S828
Chapter5IPDSProgrammingInformation 193 260071‐001A
of the line. Parameter P5 is a signed, twos-complement, one-byte value that specifies the X coordinate of
the second end point as an offset from the first end point. Parameter P6 is a signed, twos-complement,
one-byte value that specifies the Y coordinate of the second end point as an offset from the first end point.
The remaining parameters, if present, specify additional X and Y coordinate values as offsets from the
previous point, following the same format.
The printer draws the line in the current values of color, mix, line type, and line width.
This order updates the current graphics position to the coordinates of the last offset point. If there are no
offset points with this order, the current graphics position does not change.
End (END)
For a description of the End control, see “End (END)”.
Related Drawing Orders
The following list contains drawing orders that relate to a selected order. That is, when defining parameters
for a specific order, the additional orders in the list are also affected or should be considered.
Table 8. Related Drawing Order
Set Color Set Extended Color
Line, Line at Current Position
Fillet, Fillet at Current Position
Begin Area, End Area
Full Arc, Full Arc at Current Position
Begin Image
Begin Image at Current Position
Image Data, End Image
Marker, Marker at Current Position
Character String
Character String at Current Position
Relative Line
Relative Line at Current Position
Set Fractional Line Width Set Line Width
Line, Line at Current Position
Fillet, Fillet at Current Position
Full Arc, Full Arc at Current Position
Begin Area, End Area
Relative Line
Relative Line at Current Position
Set Line Type Line, Line at Current Position
Fillet, Fillet at Current Position
Full Arc, Full Arc at Current Position
Begin Area, End Area
Relative Line
Relative Line at Current Position
Set Line Width Set Fractional Line Width
Line, Line at Current Position
Fillet, Fillet at Current Position
Full Arc, Full Arc at Current Position
Begin Area, End Area
Relative Line
Relative Line at Current Position
