Other fault report outputs
Address, Port, Line
Output of a measurement fault via any module.
Impedance output flag
[OUT] Flag is active in the case of measurement faults.
Fault indication SV01
Measurement faults trigger a Summary fault on the SV01 module
Flag (NAND)
[IN] The program can be turned off by this flag or switching on can be prevented.
Flag (OR)
[IN] The program can be switched on by this flag.
10.5 Level control (loud/quiet)
Placing loud/quiet soft function (keys) on a station, to change level (Codec setting) of any module.
Note! Not to be confused with the loud/quiet soft function of ProCom stations!
Input
Address, Port
Address and port of the module to which the call station is connected, from which the
level is to be changed.
Line Loud
function
Line (key) for the "Louder" function
Line Quiet
function
Line (key) for the "Softer" function
Module to level change
Address, Port
Address and port of the module, the limit (Codec setting) of which is to be changed.
Direction
the module direction that is to be limited
10.6 Level control (attenuation) (manual/automatic)
Program for the selective attenuation of any modules with Codec, and automatic volume control in
conjunction with Module MI4M
Operation mode Control (Control by means of Flag or Line)
The program transfers the specified level to the Codec of a module on activation. When the program is
ended, the previous value is reactivated.
Flag (NAND)
[IN] The program can be turned off by this flag or switching on can be prevented.
Input
Address, Port, Line
Address, port and line (key) for activation of the program.
Latching key
Latching function for the input. The brief switching on of the input line toggles the
state.
Flag (OR)
[IN] The program can be switched on by this flag.
