10.11 Line block trigger
The transmission of Lines by means of long-distance lines takes place in fixed blocks of 8 lines each.
[ 1 - 8] [ 9 - 16] [17 - 24] [ 25 - 32] [ 33 - 40]
[41-48] [49 - 56] [57 - 64] [ 65 - 72] [ 73 - 80]
[81-88] [89 - 96] [97 -104] [105 -112] [113 -120]
A Block line is not transmitted if the state of a Line changes within a block. This static behavior can lead
to problems if, for example, the connection between networked systems is disrupted and the state of a
Line changes in the source system. When the connection is restored, the states of the lines remain
inconsistent with each other until a fresh change takes place to any Line within the block.
The Line block trigger program can counteract the problem and transmit selected blocks cyclically.
Address
Address to which the outgoing line blocks are to be triggered
Port 1-4 (Block)
Selection of blocks per port
Block-Interval time
Pause until the block is transmitted (Unit: Main loop passes)
Port-Interval time
Pause until the next port is processed (Unit: Seconds)
Program-Interval time
Pause until the program begins afresh (Unit: Seconds)
----
Reset selection completely
+++
Select all
10.12 Special trigger lines
The use of special lines can be activated in the Contact switch program by using the Long distance line
line pool option. (Range 1 to 255 lines)
This is only possible in the case of long-distance line transmission. Transmission takes place entirely as a
Single line by a single special telegram type.
As is the case with a Block line, the state of a Special line is only transmitted in the event of a change of
state. This static behavior can lead to problems if, for example, the connection between networked
systems is disrupted and the state of a Special line changes in the source system. When the connection
is restored, the state of the lines remains inconsistent in relation to each other until a fresh change of
state takes place.
The Special trigger lines program can counteract the problem and can once again begin transmitting the
states of the lines cyclically in selected areas.
Address
Address of the module, the outgoing special line of which is to be triggered.
Port 1-4 (Line)
Selection of line ares per port
Line-Interval time
Pause between the transmission of a Special line (Unit: Main loop passes)
Port-Interval time
Pause until the next port is processed (Unit: Seconds)
Program-Interval time
Pause until the program is resumed (Unit: Seconds)
