Operation mode DB-Radio
Detection for radio magazines with free- and busy tone, four-fold.
Tolerance
Identification tolerance of an incoming frequency (unit + - 10Hz)
Threshold value
required level of incoming frequency to evaluate
Gaging Count
Required number of successful measurements (50ms/measurement)
Sound (free/busy) /
Delay
Free and busy-tone generate
Delay of the output (x 50ms) due to reception/transmission switching in radio
magazine.
Line function:
Port 1 - 4:
Line 1
M -> CPU
DSS1 Busy
Line 2
CPU -> M
420Hz, 1 sec (ringback tone)
Line 3
CPU -> M
420Hz, synchronized, 1 sec (busy tone)
Line 4
CPU -> M
user-defined
Line 5
M -> CPU
1520Hz Receive
Line 6
M -> CPU
1750Hz Receive
Line 7
M -> CPU
2135Hz Receive
fixed audio channels:
Port 1 - Read Audio channel 26 (Record tone/message),
Port 2 - Read Audio channel 27 (Record tone/message),
Port 3 - Read Audio channel 28 (Record tone/message),
Port 4 - Read Audio channel 29 (Record tone/message),
Backplane connector: nonexistent
