9.19 Remote - Intercom forwarder
Transmission of Remote - Intercom connections in temporary systems
Flag (NAND)
[IN] The program can be turned off by this flag or switching on can be prevented.
Codec
audio compression process to be used (see Section 9.1)
Long distance line
Specifications of where incoming and outgoing Long distance line lines are connected.
In the case of Transmission via 2Mbps, Transmission line controlling and Transmission line AF are
identical.
Address, Port
Address of the transmission line
Control lines
The lines correspond with the Remote - Intercom program.
9.20 ZZ connection
ZZ connection refers to a intercom connection between a DVS-21 and a analog third party system. The
connection is made by means of a 4ZZA module.
Priority
Handling of priorities (see Section 9.1)
Own/Analog
Selection of the type of call station (ProCom or analog call stations).
Input/call station (Setting Own)
Address, Port, Line
Address and port of the module to which the call station is connected and the line
(key) that is used. (4NSA)
Input/call station (Setting Analog)
Address AF, Port
Address and port of the module to which the AF line of the call station is
connected. (4NPA)
Address 24LI, Port,
Line
Address, port and line of the module to which the control line of the call station is
connected. (24LI)
Call storage
Time for which the key is illuminated (flashing) after missed calls
AllCall number of own
station
A ZZ connection can react to an AllCall of the specified number. (also many) The
triggering AllCall program must must be programmed on the same station.
Illumination on lead
flag
Address, port and line (key) to be illuminated during the playback of a pre-
announcement chime or alarm tone.
Function subject to use of the Lead flag!
Special line
The line is switched on if the program is activated. For example, relays can be
switched on or keys can be illuminated.
Flag (NAND)
[IN] The program can be turned off by this flag or switching on can be prevented.)
Flag (OR)
[IN] [IN] The program can be switched on by this flag. It is possible to take over
AF channels.
Flag (OUT) 1/2
[OUT] The flag is switched on if the program is activated. Other programs can be
triggered.
Lead flag
[OUT] The flag allows the upstream switching of a pre-announcement chime or
alarm tone subject to the use of the DSS1 module and the Alarm flag in the Alarm
lead 2 program.
