Flag (OUT) 1/2
[OUT] The flag is switched on if the program is activated. This enables
further programs to be activated for adaptation to specific requirements.
AF Flag (OUT)
[OUT] Flag as before. Audio channel transfer possible.
Lead flag
[OUT] The flag enables the pre-announcement chime or alarm tone to be
connected upstream if the DSS1 module a the Alarm lead 2 program are
used.
Illumination on lead flag
Address, port and line (key) of a call station to indicate the activity of the
alarm lead. The indication is switched on for the playing time of pre-
announcement chime or alarm sound.
Suppress busy status message
Suppressing the busy indication on the call station.
9.13 Public address 2 "PA remote/local"
Program for local control of amplifiers or in remote systems for forwarding to transmission systems
Call station - Amplifier
Source and destination are part of a local system
Call station - Long distance line
Source (from station to outgoing long-distance line)
Long distance line - Long distance line
Intermediate system (connection of incoming/outgoing long-
distance line)
Long distance line - Amplifier
Destination (from incoming long-distance line on amplifier)
Priority
Handling of priorities (see Section 9.1)
Codec
Audio compression method with which the codec handles the
actual connection.
The options are: µLaw (default), ADPCM (7kHz) and aLaw (see
Section 9.1)
PA ID
ID of the Source-Destination program
Transmission via 2Mbps
AF transmission takes place via a multi-channel digital connection
(Address and port for the control system and AF are identical)
Busy message
Specifications for transmission of busy message
Call station selection - xxx
Own/Analog
Selects the type of call station (ProCom or analog call stations).
Acknowledgment
Type of display of a acknowledgment at the station
Input/call station (Setting Own)
Address, Port, Line
Address and port of the module to which the call station is
connected and the line (key) that is used. (4NSA)
Input/call station (Setting Analog)
Address AF, Port
Address and port of the module to which the AF line of the call
station is connected. (4NPA)
Address 24LI, Port, Line
Address, port and line of the module to which the control line of
the call station is connected. (24LI)
