10.7 LB splitter
Program for the transmission of LB telegrams by means of cascaded systems with local connection of a
USE2 module (upgraded Repeater mode)
Should multiple segments be switched sequentially in LB Repeater mode, then the system determines
that the total reaction time is the sum of each individual segment. If the systems are, however, connected
by means of 2Mbit lines, this program enables programs of all stations to be controlled within a very
narrow time frame.
USE2 Local
Address and port of the local USE2 mode
USE2 Recognition
ID of the LB connection
Long-distance line control
Address and port of the control system
10.8 Call number converter
Program for the transfer of a telephone number to the USE2 module. The transfer takes place by Lines or
as a telegram to Port 3.
Lines 1 - 10 correspond to the digits 1 - 9, 10 = 0, 11-14 = A-D, 15 = # and 16 = *
Output (USE2)
Address, Port
Address of the USE2 module. Reception always takes place at Port 3 of the
module.
Transfer with line
The transferral of the telephone number takes place by means of lines.
Transfer as telegram
The transferral of the telephone number takes place by means of special
telegrams.
Number of digits
Number of digits that make up the telephone number. (max. 16)
Pause between digits
Pause until transmission of the next digit as Line.
Duration of activation
The lines are active for this time.
Start delay
Pause before the program transfers the first digit as Line.
Digits
16 fields for the digits of the telephone number.
The following are valid: 0 - 9, A - D, #, * and P for Pause!
Flag (NAND)
[IN] The program can be turned off by this flag or switching on can be prevented.
Flag (OR)
[IN] The program can be switched on by this flag.
Flag (OUT) 1/2
[OUT] The flag is switched on if the program is activated. Other programs can be
triggered.
