9.11 LB forwarder
Program for transmission of LB telegrams in temporary systems, (Long distance line - Long distance line)
LB = Local Battery, operation by means of a local battery without central supply (crank and field phones)
Transmission via 2Mbps
AF transmission takes place by means of a multi-channel digital
connection (Address and port for control and AF are identical)
USE2 identifier
ID of the LB connection
Transmission line controlling
Address and port of the control system
Transmission line transmitter AF
Address and port of the module to which the AF line for the transmission
direction is connected.
Transmission line receiving AF
Address and port of the module to which the AF line for the reception
direction is connected.
Flag (NAND)
[IN] The program can be turned off by this flag or switching on can be
prevented.
9.12 PA Public address
Program for local control of an amplifier
Priority
Handling of priorities (see Section 9.1)
Codec
Audio compression method with which the codec handles the actual
connection.
The options are: µLaw (default), ADPCM (7kHz) and aLaw (see Section
9.1)
Own/Analog
Selects the type of call station (ProCom or analog call stations).
Input/call station (Setting Own)
Address, Port, Line
Address and port of the module to which the call station is connected and
the line (key) that is used. (4NSA)
Input/call station (Setting Analog)
Address AF, Port
Address and port of the module to which the AF line of the call station is
connected. (4NPA)
Address 24LI, Port, Line
Address, port and line of the module to which the control line of the call
station is connected. (24LI)
Activated amplifier
Address and port of the amplifier (V100 or external via 4NPA)
Device ID (only with 4DSS and UZ-ELA)
Relay 1/2
These lines are ON when the program is active. e.g. relay can be switched
or keys are illuminated.
AllCall number of own station
This program can be integrated as a destination in a AllCall. The
association is determined by one or multiple AllCall numbers.
The AllCall program must be running of the specific station.
Flag (NAND)
[IN] The program can be turned off by this flag or switching on can be
prevented.
Flag (OR)
[IN] The program can be switched on by this flag. It is possible to take over
AF channels.
