9.8 Intercom radio monitoring
Program for switching on monitoring option for radio on stations or PA loudspeakers. Only suitable when
used in connection with ProCom stations and their monitoring connection(Ma/b)!
Start function
Address, port and line (key) to activate the program. (4IOS, 24LI)
Radio AF
Address and port of the module (usually 4NPA), to which the AF line of the radio station
is connected.
Monitor address
Address and port of the AF module to which the monitoring connection Ma/b is
connected.
Tone call
To suppress the Tone call frequencies
Address, port and line of the module for Tone call evaluation (DSS1) or another module
that provides the information (remote control)
Flag (NAND)
[IN] The program can be turned off by this flag or switching on can be prevented.
Flag (OR)
[IN] The program can be switched on by this flag. It is possible to take over AF channels.
Flag (OUT) 1/2
[OUT] The flag is switched on if the program is activated. This enables further programs
to be activated for adaptation to specific requirements.
9.9 AllCall
The AllCall program functions locally. Only destinations to which a voice connection can be established
from the specific station by means of one of the following programs can be integrated: (IC Intercom, IC
Group, PA Public address, ZZ connection).
Stations in remote systems can be addressed locally by means of the Remote - AllCall program and in
the destination system by means of the Remote - Intercom program. In this instance, however, there is no
option of using the pre-announcement chime or the alarm tone.
Priority
Handling of priorities (see Section 9.1)
Codec
Audio compression method with which the codec handles the actual connection.
The options are: µLaw (default), ADPCM (7kHz) and aLaw (see Section 9.1)
AllCall No.
ID of the connection
Own/Analog
Selects the type of call station (ProCom or analog call stations).
Input/call station (Setting Own)
Address, Port, Line
Address and port of the module to which the call station is connected and the line
(key) that is used. (4NSA)
Input/call station (Setting Analog)
Address AF, Port
Address and port of the module to which the AF line of the call station is connected.
(4NPA)
Address 24LI, Port,
Line
Address, port and line of the module, to which the control line of the call station is
connected. (24LI)
