10.3 Flag timing
Program for triggering of actions at fixed time intervals.
e.g. Impedance measurement, Level reduction at night (V100)
Send time stamp to interface
The current system time is sent to the module specified under Output.
(4LSL in conjunction with the Temperature profile)
Date Time
Output date, Output time
The output time is to be specified according to the interval. The date is not
required for the hourly and daily option!
Interval
Triggering Interval
Duration
Outputs are active for this time
Output 1/2
Address, port and line for a module
Flag (NAND)
[IN] The program can be turned off by this flag or switching on can be
prevented.
Flag (OUT) 1/2
[OUT] The flag is switched on if the program is activated. Other programs
can be triggered.
Clear output flag 1/2
[IN] Flag switches the respective Flag (OUT) off
Special function: System Reset
The ALT-R key combination superimposes a text field. By entering the word "reset", the program goes
into Reset Mode. In this mode, the program triggers a system reset at the set time.
This mode can be ended by canceling the program!
10.4 Impedance measurement
Process control for internal impedance measurement of the V100 amplifier
Not to be confused with Impedance measurement by the 4LSL module!
The program controls one or more V100 by means of their Impedance flag and evaluates the measured
values.
Automatic measurements at specific times are performed by the Flag timing program by means of the
Flag (OR).
Connection to amplifier
Impedance flag
[IO] Flag for control of the measurement in the amplifier V100
Tolerance
Deviation of the instantaneous measured value from the stored reference value of the
respective V100.
The tolerance is specified in percent or digits. For V100 versions as from Firmware
x129 only Tolerance in steps (Digit) is to be used!
Start function
Address, Port, Line
Starting of measurement by a line
Illumination line
Address, Port, Line
Address, port and line (key) to display the status
The LED flashes when measurement is active.
The LED glows continuously in the event of a measurement fault.
