8.4 PCS (PC call station)
The connection of one or more PCS is at the Ethernet connector of the module LCPU. The setting of a
PCS as a call station is for the documentation at this time.
Station number
Unique number of the device
The number belongs to the pool of the call station numbers in the system and it
must be unique.
Module address, Port
Address and port of the module at which the PCS is connected. (LCPU)
Name
Labeling for the call station
The button Get adopts a noted description from Address description.
8.5 Measuring mic
It is necessary to register a Measuring mic as a call station so that the monitoring of the fuses of the
module MI4M is activated by the CPU.
Station number
Unique number of the device
The number belongs to the pool of the call station numbers in the system and it
must be unique.
Module address, Port
Address and set of the module at which the Measuring mic is connected. (MI4M)
Name
Labeling for the Measuring mic
The button Get adopts a noted description from Address description.
8.6 Separate amplifier
Spatially separated analog amplifiers can be controlled by using the Separate amplifier function. Control
takes place by means of the 4DSS (RS485) module and UZ-ELA modules connected to it.
The UZ-ELA-Module enables remote PA.
A 2W-Amplifier is integrated.
External PA-Amplifiers can be connected. By feeding the loudspeaker line back to the 100V-input, it is
possible to monitor the loudspeaker line.
UZ-ELA = Control sub-center for loudspeaker system (German derivation "UnterZentrale für
Elektronische LautsprecherAnlage")
Configuration of the Separate amplifier device takes place in the Call stations and devices dialog.
Programming takes place by means of the PA Public address program.
Settings
Amplifier No.
Unique number of the amplifier in the system
Address, Port
Address and port of the module to which the RS485 data line of the UZ-ELA module is
connected. (4DSS)
Subscriber
No.
ID for addressing the module
(see Activated amplifier in Program PA Public address)
Volume
Volume/Level of the amplifier
System call
Integration in a system AllCall. (see AllCall)
Online level
Level is transferred to the amplifier
