General data
Common adjustments like the identity, behavior and level of a call station.
Type
Differentiation in the connection technology (2-wire or 4-wire)
Module address, Port
Address and port to which the call station is attached
Name
Unique number of the device
The number belongs to the pool of the call station numbers in the system and it
must be unique.
The button Get adopts a noted description from Address description.
Micro control
Sensitivity of the microphone pre-amplifier (adjustment range)
Intercom interval time
The levels for the call station and the additional amplifier can be adjusted
automatically on the level Call by the first response after that the level Normal is
adjusted and used as long as in the adjusted time is spoken.
Flag Night operation
Flag for the activation of the night operation.
On activated Flag/L> the Level Night is adjusted.
(an adjustment of time can be realized with the program Flag timing)
Level-Radio monitoring
(only Desktop)
Level of play back signal which is provided via the monitor input Ma/b into the call
station.
Booster amplifier
All ProCom call stations can be operated with a 25 W Booster amplifier. The
weatherproof call stations (WPSxx) have a built-in amplifier. Into the Desktop-
and Flush mount- call stations the external amplifier "BA-25" has to be
additionally mounted.
Level Normal
Normal level of the play back
Level Call
Raised level by the first response (only with Intercom interval time)
Level Night
Level during active Flag Night operation
Activate
Activates the online status for the dialog
Online level
Transmission of the values Receive level, Micro control and Level-Radio
monitoring.
Attention! Online transmitted values are not permanently saved! Measured
values must be saved while programming and saved into the system.
Default Level
Sets all levels on the default values of System data Default volume - intercom.
Keys
Programming takes place by means of selection from the list Programs and a click on the desired key in
the display. A click on a programmed click (Line) opens an existing program.
Programming of a key (Line) can also take place via the program overview by direct input of the address,
port and line (key) in the desired program!
Programmed keys (Lines) are displayed in color in accordance with the legend!
Required housings
Depending on the selection of the No. of keys when setting up a call station, (Creating
a call station) the respective additional housings is listed here in addition to the basic
housing. One can toggle between the devices by clicking on the list.
