RED - FLASHING
Impedance error detected (short
circuit)
RED - FLASHING (fast)
Impedance error detected (line
break)
AL2
RED - ON
Earth fault detected
Backplane connectors:
AMP a/b
- Input from amplifier
SPK a/b
- Output to the loudspeakers
M a/b
- Measuring frequency input from TG01
7.18 4DSS
The module is designed to connect UZ-ELA modules. UZ-ELA = Control sub-center for loudspeaker
system (German derivation "UnterZentrale für Elektronische LautsprecherAnlage").
All interfaces (RS485) are galvanic isolated, protected against overvoltage and overcurrent.
The UZ-ELA-module allows remote PA.
A 2W-amplifier is integrated.
External PA-amplifiers can be connected. The feedback of the loudspeaker cable to the 100V input
enables the monitoring of the loudspeaker line.
The configuration of UZ-ELA modules is done with Separate amplifier in the menu Call stations and
devices.
Backplane connectors:
+/-
- Power supply
a/b
- Line
