Shuttle Error Messages
ERROR MESSAGE CAUSE SOLUTION
"ERROR.SHUTTLE_COAT_FAILURE"
"ERROR.SHUTTLE_HOME_FAILURE"
"ERROR.SHUTTLE_FILL_FAILURE"
"ERROR.SHUTTLE_SCRAP_FAILURE"
THE SHUTTLE FAILED TO
MAKE SCRAPE POSITION.
THE SHUTTLE FAILED TO
MAKE HOME POSITION.
THE SHUTTLE FAILED TO
MAKE FILL POSITION.
THE SHUTTLE FAILED TO
MAKE SCRAP POSITION.
UNLOCK THE DOOR AND OPEN TO CHECK FOR
OBSTRUCTION. IF NONE: 1- CLOSE AND LOCK DOOR
2- GO TO ADVANCED\DIAGNOSTICS ON THE MENU BAR.
3- OPEN SHUTTLE MOTION TAB
4- CLICK ON HOME BUTTON AND INSURE HOME POSITION ˜
CURRENT POSITION
5- CLICK ON MOVE TO SCRAPE AND INSURE SCRAPE
POSITION ˜ CURRENT POSITION
6- CLICK ON MOVE TO COAT AND INSURE COAT POSITION ˜
CURRENT POSITION
7- IF STEPS 4-6 DO NOT MAKE THE TARGET POSITIONS:
REMOVE MATERIAL CARTRIDGE
UNLOCK AND OPEN DOOR
RAISE SHUTTLE FRAME AND CHECK FOR
OBSTRUCTION IN EITHER MATERIAL TRAY OR
SHUTTLE FRAME TRACKS
IF NO OBSTRUCTION, TURN OFF PRINTER AND DO
MAINTENANCE CLEANING OF SHUTTLE PLATE AND
RAILS
