Electrical
During normal operation, the power usage of the printer will not exceed the continuous current rating. Ensure that the power supply is at least 6
amps.
European-style circuit breaker or other protective equipment rated for lower levels of protection are not recommended, and risk damage to the
unit's internal electronic components.
Electrical Specifications
Maximum Power
5 Amp for 100 to 120 VAC~, 2.5 Amp. for 220 to 240 VAC~
Power Consumption
400 W
Input Voltage (auto range)
100 - 240 VAC~, 50/60 Hz
Power Cable (for single phase power)
3-Conductor, wire size according to local electrical code
Recommend use of a back-up power supply and surge protector rated for at least 1000 VA.
Note: The installation of the printer shall comply with the National Standards and Electrical Codes of the country in which it is
placed.
