PROLEC James Fisher PME400 User Manual

562400-000, Issue 1.3 January 2022
Page 42 of 61
Once the limits are set, the internal alarm will sound and the RED LED
will light if the equipment reaches either limit. Always check that the
current limit activates at the set points. The restriction cannot be
deactivated if in the alarm state. Do not travel once a slew limit has
been set. Observe the operational limitations given in section 4.
Safe Directional Indicators. The triangles
indicate if it is safe GREEN, or unsafe RED
to movement a particular articulation.
PME 405 only: AMBER arrows indicate
that motion is slowed in that direction
Safe Directional Indicators. The
left and right arrows indicate if it
is safe GREEN, or unsafe RED
to slew in that direction.
PME 405 only: AMBER arrows
indicate that motion is slowed in
that direction

PROLEC James Fisher PME400 Specifications

General

Brand	PROLEC
Model	James Fisher PME400
Category	Controller
Language	English
