15.3.3 Event messages in the log book
Tab. 26: Events
Log book no. Description
0 Head change is active – dongle was inserted.
1 Parameter menu called up – dongle was inserted.
2 Air gap measured – dongle was inserted.
3 Too high current was detected but no fault message generated.
5 Automatic bleed was active.
7 The pump was reset to factory settings.
8 The pump was calibrated.
9
[START/STOP]
was pressed.
10
[Priming]
was pressed.
11 The
[Clickwheel]
was pressed.
12 The diaphragm was replaced.
13 The timer has performed an action.
15 Solenoid identification was performed.
16 A CRC error has been detected in the EEProm data.
Log book: [hh ll 00 00]
hh – MSB address
ll – LSB address
[00 00 rr ss]
ss – Struct
rr – Result
17 Overloading has been detected.
Log book:
[00 PP zz ii]
PP – Solenoid power [W]
zz – Uzk [V]
ii – Solenoid current [ * 100 mA]
18 The metering volume cannot be metered. In
‘Contact’
operating mode, e.g. by too
fast a contact sequence.
19 The pump has been booted and is operational.
21 An SDO request to the power unit was unsuccessful.
Explanatory data:
[01 00 00 00] – When reading the maximum capacity
[02 00 00 00] – When reading the maximum volume per stroke
[04 00 00 00] – When reading the minimum possible volume per stroke
[08 00 00 00] – When reading a standard SDO request
Troubleshooting
