12 Operation
This chapter describes all the operating options in a continuous
display (several symbols and the pressure display appear at the
top in the black bar) for the person trained on the pump.
–
Please also refer to the "Operating/Setting
overview" and "Continuous displays and sec‐
ondary displays" overviews at the end of the
operating instructions and also the "Overview
of equipment and control elements" chapter.
12.1 Manual operation
Stop the pump: Press
[STOP/START]
.
Start the pump: Press
[STOP/START]
again.
Press
[Priming]
.
Turn the
[Clickwheel]
to lengthen or shorten the priming time
during priming.
In
‘Batch’
operating mode: Press the
[Clickwheel]
in the
‘Push’
continuous display.
Press the
[Clickwheel]
to acknowledge error messages that require
acknowledgement.
In a continuous display: Another continuous display appears each
time the
[Clickwheel]
engages when turned. (The number depends
on the configuration.)
1. Press the
[Clickwheel]
.
ð
The variable can be changed (highlighted).
2. Turn the
[Clickwheel]
.
ð
The variable is changed.
3. Press the
[Clickwheel]
.
ð
The variable is saved (the highlighting disappears).
If the "lock" - "lock all" has been set - see
Ä ‘Set-up overview
gamma/ XL’ on page 98
, first enter the
‘Password’
after pressing
the
[Clickwheel]
.
List of directly changeable variables:
n Capacity
n Stroke rate
n Stroke length
n Factor
Stop/start pump
Priming
Start a batch
Acknowledging errors
Check adjustable variables
Changing directly adjustable variables
Changing a variable in the relevant
continuous display:
Operation
97
