There is no ‘Pressure adjustment’ sub-menu with
pumps with SER dosing heads.
Requirements:
n A manometer is installed in the discharge line.
n Everything is set on the pump.
1. Shift to the
‘Pressure adjustment’
sub-menu.
ð
The
‘Start pump’
menu item appears.
2. Use the
[Clickwheel]
to confirm
‘Yes’
.
ð
The pump starts up.
The
‘Calibration pressure’
menu item appears.
3. The
‘Calibration pressure’
menu item shows at the top the
pressure value that the pump is missing. Below that it dis‐
plays an adjustable pressure value.
4. Use the
[Clickwheel]
to enter the pressure value from the
manometer as soon as the pressure value is stable.
5. Use the
[Clickwheel]
to confirm this pressure value.
ð
The pump stops.
‘Pressure adjustment’
is now complete.
11.2.7.5 Start behaviour
‘Menu / Information
è
Settings
è
System
è
Start behaviour
è
...’
You can specify the start behaviour of the pump once the supply
voltage has been switched on in the
‘Start behaviour’
sub-menu.
Start behaviour Description
‘always STOP’
The pump always wakes up in “Manual
stop via the
[STOP/START]
key" mode.
It can only be started by pressing
[STOP/START]
.
‘always on’
The pump always starts immediately.
‘last status’
The pump always adopts the last status it
had before the supply voltage was
switched off.
11.2.8 Inputs/outputs
‘Menu / Information
è
Settings
è
Inputs/outputs
è
...’
Set up /
‘Menu’
70
