ProMinent gamma XL User Manual

The
‘Inputs/outputs’ menu is split into the following sub-menus:
1 - ‘Auxiliary capacity’ / ‘Auxiliary frequency’
2 - ‘Relay1’ (optional)
3 - ‘Relay2’ (optional)
4 - ‘Flow monitor’ (only if connected)
5 - ‘Diaphragm rupture’ (only if connected)
6 - ‘Pause input’ (optional)
7 - ‘Niveau monitoring’
11.2.8.1 ‘Auxiliary capacity’ / ‘Auxiliary frequency’
‘Menu / Information è Settings è Inputs/Outputs
è Auxiliary capacity / Auxiliary frequency è ...’
The programmable ‘Auxiliary capacity’ / ‘Auxiliary frequency’ func‐
tion enables switch-over to an additional capacity / stroke rate that
can be fixed in the ‘Auxiliary capacity’ / ‘Auxiliary frequency’
menu.
It can be activated via the "External control” terminal. If ‘Auxiliary
capacity’ / ‘Auxiliary frequency’ is being used, then the identifier
"AUX” appears on the LCD screen.
Refer to the "Hierarchy of operating modes, functions and fault sta‐
tuses" for the order of the various operating modes, functions and
fault statuses.
11.2.8.2 ‘Relay1 (optional)’
‘Menu / Information è Settings è Inputs/outputs è Relay1
è ...’
The setting options for the ‘Relay’ function are
only available if a relay is fitted.
Tab. 17: Relay, physical and pre-set to ...
Identity code specification Relay, physical Pre-set to ...
1 1 x changeover contact 230 V – 8
A
Fault indicating relay, N/C
4 2 x N/O 24 V – 100 mA Fault indicating relay, N/C, and
pacing relay
You can reprogram the relays to these types:
gamma/ XL, GXLa
Relay type
Set up /
‘Menu’
71
