Identifier Meaning
‘Metering
è
Discharge stroke
è
HV1’
metering profile has been set.
‘Metering
è
Suction stroke
è
HV2’
metering profile has been set.
‘Metering
è
Suction stroke
è
HV3’
metering profile has been set.
A "Flow Control" metering monitor is connected.
A diaphragm rupture indicator is connected.
The pump has created a log about the operation.
The pump is in the
‘Menu’
(Set up).
Further explanations can be found in the "Trouble‐
shooting" chapter.
The pump only shows the metering volume and
the capacity in the calibrated state in l or l/h or in
gal or gal/h.
5.2.2 Key functions
Key Application In the continuous displays In the menu
[Back]
press - Move back to the previous
menu point (or a continuous
display) - without saving
[STOP/
START]
press Stop pump, Stop pump,
Start pump Start pump
[Menu]
press Move to the menu Move back to a continuous dis‐
play
[Priming]
press Priming * Priming *
