4. To run through the figures again, if necessary (possibly
because of an incorrect figure), when you get to the last
figure press
[Priming]
again - see above Figure, point c).
ð
Now you can start from the beginning again.
Press the
[Clickwheel]
1x.
ð
The software saves the entry.
10.2 Checking adjustable variables
Before adjusting the pump, you can check the current settings of
the adjustable variables:
Simply turn the
[Clickwheel]
if the pump is showing a contin‐
uous display.
ð
Each time the
[Clickwheel]
engages when you turn it, you
will see a different continuous display.
The number of continuous displays depends on
the identity code, the selected operating mode and
the connected additional devices – see overview of
"Continuous displays" in the appendix.
The lowest line of a continuous display shows different information
(which cannot be adjusted in the secondary display) - see "Contin‐
uous displays and secondary displays" overview in the appendix.
You can access secondary displays via any continuous display as
follows:
1. Press the
[Clickwheel]
for 3 seconds.
ð
A frame appears around the secondary display.
2. Providing there is a frame, you will see a different secondary
display each time the
[Clickwheel]
engages when turned.
When you reach the secondary display you wish, leave the
[Clickwheel]
and wait briefly.
10.3 Changing to Setting mode
In a continuous display, if you press
‘Menu’
, the pump in Set‐
ting mode changes to
‘Menu’
. For more information refer to the fol‐
lowing chapter entitled "Set up / Menu".
If under
‘Access protect.’
only
‘Menu’
or
‘All’
has been set up (top
right
lock symbol), then after pressing the
[Clickwheel]
, first
enter the
‘Password’
.
Confirming adjustable variables
Continuous displays
Secondary displays
Basic set-up principles
48
