The number of strokes per pulse depends on the factor which you
can input. By using a factor you can multiply incoming pulses by a
factor between 1.01 to 99.99 or reduce them by a factor of 0.01 to
0.99:
Number of strokes executed = factor x number of
incoming pulses
Factor Pulse (sequence) Number of strokes
(sequence)
Step-up*
1 1 1
2 1 2
25 1 25
99.99 1 99.99
1.50 1 1.50 (1 / 2)
1.25 1 1.25 (1 / 1 / 1 / 2)
Step-down**
1 1 1
0.50 2 1
0.10 10 1
0.01 100 1
0.25 4 1
0.40 2.5 (3 / 2) (1 / 1)
0.75 1.33 (2 / 1 / 1) (1 / 1 / 1)
Tab. 8: * Explanation of step-up
With a factor of 1 ... 1 stroke is executed per 1 pulse
With a factor of 2 ... 2 strokes are executed per 1 pulse
With a factor of 25 ... 25 strokes are executed per 1 pulse
Tab. 9: ** Explanation of step-down
With a factor of 1 ... 1 stroke is executed per 1 pulse.
With a factor of 0.5 ...1 stroke is executed after 2 pulses.
With a factor of 0.1 ...1 stroke is executed after 10 pulses.
With a factor of 0.75 ...1 stroke is executed once after 2 pulses,
then 1 stroke is executed twice after 1 pulse,
and then again 1 stroke after 2 pulses etc.
Table of examples
(
‘Automatic’
‘Off’
) factor
Set up /
‘Menu’
51
