The setting options for the ‘Flow control’ function
are only available if a flow control is electrically
installed. The symbol for flow control appears:
.
A metering monitor, such as a Flow Control (also DulcoFlow
®
), can
register the individual pressure impacts of the pump and report
them back to the pump.
The pump switches to fault mode if this feedback is missing in a
sequence, as set under
‘Error tolerance’
.
It is possible to switch the function on and off under
‘Activation’
.
Under
‘at Auxiliary’
, it is possible to set whether the function is to
be deactivated with auxiliary frequency.
11.2.8.6
‘Diaphragm rupture’
‘Menu / Information
è
Settings
è
Inputs/outputs
è
Diaphragm rupture
è
...’
The setting options for the ‘Diaphragm rupture’
function are only available if a diaphragm rupture
indicator is electrically installed. The symbol for
diaphragm appears
.
In the
‘Diaphragm rupture’
sub-menu you can select whether the
pump generates a warning message or an error message in the
event of a diaphragm rupture.
11.2.8.7
‘Pause input’
‘Settings
è
Inputs/outputs
è
Pause
è
...’
In the
‘Pause’
menu you can select whether the pump switches to
‘Pause’
with an "Energizing (N/O)" or "Releasing (N/C)" input con‐
tact signal.
11.2.8.8
‘Niveau monitoring’
‘Settings
è
Inputs/outputs
è
Niveau monitoring
è
...’
Select in the which measuring principle is to be used for level mon‐
itoring in the
‘Niveau monitoring’
menu:
n
‘2-stage’
n
‘continuous’
11.2.8.8.1 2-stage
In the
‘Level warning’
sub-menu, you can select for a two-stage
level switch whether the pump switches to
‘Level warning’
with a
‘Break contact’
or
‘Make contact’
input contact signal.
Set up /
‘Menu’
74
