PLX3x Series Multi-Protocol Gateways ASCII Protocol
User Manual
ProSoft Technology, Inc. Page 149 of 215
January 25, 2018
Port 1 Status Data
Status Register
Description
13010
Receive State:
-1 = Listening for data
1 = Receiving Port Data
2 = Waiting for Backplane transfer
13011
Receive character count
13012
Receive message count
13013
Transmit State:
0 = Waiting for Data to Send
1 = RTS On
2 = RTS Timeout
3 = Sending data
4 = Waiting for RTS Off
5 = RTS turned off
30 = Intercharacter Delay
31 = Intercharacter Delay
32 = Intercharacter Delay
100 = Message Delay before Transmit
101 = Message Delay before Transmit
13014
Transmit character count
13015
Transmit message count
13016
Configuration error word
13017 to 13019
No Valid Data
