ProSoft Technology PLX3x Series User Manual

PLX3x Series ♦ Multi-Protocol Gateways ASCII Protocol
User Manual
ProSoft Technology, Inc. Page 151 of 215
January 25, 2018
Port 3 Status Data
Status Register
Description
13030
Receive State:
-1 = Listening for data
1 = Receiving Port Data
2 = Waiting for Backplane transfer
13031
Receive character count
13032
Receive message count
13033
Transmit State:
0 = Waiting for Data to Send
1 = RTS On
2 = RTS Timeout
3 = Sending data
4 = Waiting for RTS Off
5 = RTS turned off
30 = Intercharacter Delay
31 = Intercharacter Delay
32 = Intercharacter Delay
100 = Message Delay before Transmit
101 = Message Delay before Transmit
13034
Transmit character count
13035
Transmit message count
13036
Configuration error word
13037 to 13039
No Valid Data
