ProSoft Technology PLX3x Series User Manual

PLX3x Series ♦ Multi-Protocol Gateways EIP Protocol
User Manual
ProSoft Technology, Inc. Page 55 of 215
January 25, 2018
EtherNet/IP Explicit Messaging Server Command Support
The PLX3x gateway supports several command sets.
Basic Command Set Functions
Command
Function
Definition
Supported in Server
0x00
N/A
Protected Write
X
0x01
N/A
Unprotected Read
X
0x02
N/A
Protected Bit Write
X
0x05
N/A
Unprotected Bit Write
X
0x08
N/A
Unprotected Write
X
PLC-5 Command Set Functions
Command
Function
Definition
Supported in Server
0x0F
0x00
Word Range Write (Binary Address)
X
0x0F
0x01
Word Range Read (Binary Address)
X
0x0F
Typed Range Read (Binary Address)
X
0x0F
Typed Range Write (Binary Address)
X
0x0F
0x26
Read-Modify-Write (Binary Address)
0x0F
0x00
Word Range Write (ASCII Address)
X
0x0F
0x01
Word Range Read (ASCII Address)
X
0x0F
0x26
Read-Modify-Write (ASCII Address)
SLC-500 Command Set Functions
Command
Function
Definition
Supported in Server
0x0F
0xA1
Protected Typed Logical Read With Two
Address Fields
X
0x0F
0xA2
Protected Typed Logical Read With Three
Address Fields
X
0x0F
0xA9
Protected Typed Logical Write With Two
Address Fields
X
0x0F
0xAA
Protected Typed Logical Write With Three
Address Fields
X
0x0F
0xAB
Protected Typed Logical Write With Mask (Three Address Fields)
