EIP Error Codes
Code (Int)
Code (Hex)
Description
-1
0xFFFF
CTS modem control line not set before transmit
-2
0xFFFE
Timeout while transmitting message
-10
0xFFF6
Timeout waiting for DLE-ACK after request
-11
0xFFF5
Timeout waiting for response after request
-12
0xFFF4
Reply data does not match requested byte count
-20
0xFFEC
DLE-NAK received after request
-21
0xFFEB
DLE-NAK sent after response
-200
0xFF38
DLE-NAK received after request
TCP/IP Interface Error Codes
Error (Int)
Error (Hex)
Description
-33
0xFFDF
Failed to connect to target
-34
0xFFDE
Failed to register session with target (timeout)
-35
0xFFDD
Failed forward open response timeout
-36
0xFFDC
PCCC/Tag command response timeout
-37
0xFFDB
No TCP/IP connection error
Common Response Error Codes
Error (Int)
Error (Hex)
Description
-40
0xFFD8
Invalid response length
-41
0xFFD7
CPF item count not correct
-42
0xFFD6
CPF address field error
-43
0xFFD5
CPF packet tag invalid
-44
0xFFD4
CPF bad command code
-45
0xFFD3
CPF status error reported
-46
0xFFD2
CPF incorrect connection ID value returned
-47
0xFFD1
Context field not matched
-48
0xFFD0
Incorrect session handle returned
-49
0xFFCF
CPF not correct message number
Register Session Response Error Codes
Error (Int)
Error (Hex)
Description
-50
0xFFCE
Message length received not valid
-51
0xFFCD
Status error reported
-52
0xFFCC
Invalid version
