Start Here MVI56-PDPMV1 ♦ ControlLogix Platform
User Manual PROFIBUS DPV1 Master
Page 10 of 251 ProSoft Technology, Inc.
100 Mbytes of free hard disk space (or more based on application
requirements)
256-color VGA graphics adapter, 800 x 600 minimum resolution (True Color
1024 x 768 recommended)
Dial-up Internet connection (Broadband connection recommended)
Approved PROFIBUS cabling and connectors
Small flat blade screwdriver to secure the PROFIBUS connector to the
module
Note: You can install the module in a local or remote rack. For remote rack installation, the module
requires Ethernet I/P or ControlNet access to the processor.
1.2 Package Contents
The following components are included with your MVI56-PDPMV1 module, and
are all required for installation and configuration.
Important: Before beginning the installation, please verify that all of the following items are
present.
Cable #15 - RS232
Null Modem
For RS232 between a Personal Computer
(PC) and the CFG port of the module
Cable #14 - RJ45
to DB9 Male
Adapter
For connecting the module’s port to Cable
#15 for RS-232 connections
If any of these components are missing, please contact ProSoft Technology
Support for replacement parts.
