Mailbox Messaging MVI56-PDPMV1 ♦ ControlLogix Platform
User Manual PROFIBUS DPV1 Master
Page 166 of 251 ProSoft Technology, Inc.
3.5.10 Mailbox Message: Start Slave
This mailbox message starts a selection of slaves that was previously removed
from the processing cycle by means of the mailbox message
FB_APPL_STOP_SLAVE.
This message is allowed in all Operation modes (STOP, CLEAR and
OPERATE).
Note: The message will be accepted even if one or several slaves are not part of the configuration
and can therefore obviously not be started. However, the application can find out about this
situation by evaluating the "Fault information" and "Message data words" of the response.
Command and Response Layout: Start Slave
Command
Response
Message ID
(ID)
(ID)
Message information
4002h
0002h
Command
000Bh
000Bh
Start Slave
Data size
007Eh
007Eh
Frame count
0001h
0001h
Frame number
0001h
0001h
Offset high
0000h
0000h
Offset low
0000h
0000h
Extended word 1
Extended word 2
-
-
Extended word 3
-
-
Extended word 4
-
-
Extended word 5
-
-
Extended word 6
-
-
Extended word 7
-
Additional Fault Information
Extended word 8
-
Fault Information
Message data word 1
Slave 0
Slave 1
Slave 0
Slave 1
Message data word 2
Slave 2
Slave 3
Slave 2
Slave 3
Message data word 3 to 62
...
...
...
..
Message data word 63
Slave 124
Slave 125
Slave 124
Slave 125
