3.2.3 Sending Mailbox Commands
The mailbox commands allow the processor to request specific tasks from the
module. The following table describes the available mailbox commands:
Mailbox
Controller Tag
Overview
Trigger
Data
Acyclic Read
MVI56PDPMV1.Command.
AcyclicRead
MVI56PDPMV1.Mailbox.
AcyclicRead
Reads acyclic data information from DPV1
slaves
Acyclic Write
MVI56PDPMV1.Command.
AcyclicWrite
MVI56PDPMV1.Mailbox.
AcyclicWrite
Writes acyclic data information from DPV1
slaves
Get Live List
MVI56PDPMV1.Command.
GetLiveList
MVI56PDPMV1.Mailbox.
GetLiveList
Reads the live list from the module. The live
list shows which slave addresses are
currently communicating with the module
Get Slave
Configuration
MVI56PDPMV1.Command.
GetSlaveConfig
MVI56PDPMV1.Mailbox.
GetSlaveConfig
Reads the configuration (identifier bytes) from
a specific connected PROFIBUS slave
Get Slave
Diagnostics
MVI56PDPMV1.Command.
GetSlaveDiagnostics
MVI56PDPMV1.Mailbox.
GetSlaveDiagnostics
Reads slave diagnostics from a specified
slave
Set Clear Mode
MVI56PDPMV1.Command.
SetClearMode
-
Sets the module in CLEAR mode. This is an
option for the Set Operating Mode mailbox.
Set Operate
Mode
MVI56PDPMV1.Command.
SetOperateMode
-
Sets the module in OPERATE mode. This is
an option for the Set Operating Mode
mailbox.
Set Stop Mode
MVI56PDPMV1.Command.
SetStopMode
-
Sets the module in STOP mode. This is an
option for the Set Operating Mode mailbox.
Set Slave
Address
MVI56PDPMV1.Command.
SetSlaveAddress
MVI56PDPMV1.Mailbox.
SetSlaveAddress
Sets the node address of a specified slave (if
supported at slave)
Set Slave Mode
MVI56PDPMV1.Command.
SetSlaveMode
MVI56PDPMV1.Mailbox.
SetSlaveMode
Sets control commands to slaves or group of
slaves (sync, freeze, unsynch, unfreeze)
Start Slaves
MVI56PDPMV1.Command.
StartSlaves
MVI56PDPMV1.Mailbox.
StartSlaves
Reinitializes communication with a slave after
interrupted through Stop Slaves mailbox
Stop Slaves
MVI56PDPMV1.Command.
StopSlaves
MVI56PDPMV1.Mailbox.
StopSlaves
Stops communication with specified slaves
