To send a mailbox request
1 Enter the mailbox configuration parameters (if applicable) in the following
controller tag:
MVI56PDPMV1.Mailbox.<MailboxName>.Out.<ParameterName>
Note: This step is not applicable to the following mailboxes (no parameters required):
 SetClearMode
 SetStopMode
 SetOperatingMode
 GetLiveList
2 Toggle the mailbox trigger bit MVI56PDPMV1.Command.<MailboxName>
3 Verify that the mailbox trigger bit is automatically reset
4 Verify that the message to request the mailbox was successfully executed
through the increment of the following controller tag:
MVI56PDPMV1.Util.MSG.MailboxRequest.DNCounter.ACC
5 Verify that the message to retrieve the mailbox response was successfully
executed through the increment of the following controller tag:
MVI56PDPMV1.Util.MSG.MailboxResponse.DNCounter.ACC
6 Refer to the mailbox response data (if applicable) in the following controller
tag: MVI56PDPMV1.Mailbox.<MailboxName>.In.<ResponseDataName>
Note: This step is not applicable to the following mailboxes (no response data):
 SetClearMode
 SetStopMode
 SetOperatingMode
