ProSoft MVI56-PDPMV1 - Page 236

Reference MVI56-PDPMV1 ♦ ControlLogix Platform
User Manual PROFIBUS DPV1 Master
Page 236 of 251 ProSoft Technology, Inc.
Byte Offset
Start
End
Name
Description
118
119
File Error Word
This is bit-mapped value that indicates which files are not
present.
Bit 0: Problem with PDPMV1.CFG file
Bit 1: Not used
Bit 2: Problem with PDPMV1.DDB file
Bit 3: Problem with PDPMV1.XML file
Bits 4 to 15 not used.
If this word has a value other than 0, the CFG ERR LED on the
module will be illuminated.
120
145
Reserved
Reserved for future use
146
147
In mailbox queue count
Number of message in the in mailbox queue
148
149
Out mailbox queue
count
Number of message in the out mailbox queue
150
151
Alarm queue count
Number of message in the alarm queue
152
153
Last out mailbox
message ID processed
from output image
Last out mailbox message ID processed from output image
154
155
Current in mailbox
control index
Current in mailbox control index
156
157
Current alarm control
index
Current alarm control index
158
496
Reserved for future use
496
497
Index of Output image to receive (1 to 4 for data, 0 or -1 if no
data)
498
499
Block index of -1 or 0 for status block
