MBS.CONTROL.EventCmd_ProcessorData
This array allows the processor to dynamically build Modbus commands with
processor data. This feature is meant for periodic execution such as resetting the
clock and zeroing-out counters.
Tag Name
Range
Description
MBS.CONTROL.EventCmd_Processor
Data.CmdTrigger
0 or 1
Toggle to send Event Command.
0 = Disable, 1 = Enable
MBS.CONTROL.EventCmd_Processor
Data.GetStatusTrigger
0 or 1
Toggle to retrieve event status.
0 = Disable, 1 = Enable
MBS.CONTROL.EventCmd_Processor
Data.PortNumber
1 or 2
Port number to be associated with
command
MBS.CONTROL.EventCmd_Processor
Data.SlaveAddress
1 to 248
Slave ID of Modbus slave
MBS.CONTROL.EventCmd_Processor
Data.ModbusFunctionCode
-
Modbus function code (5,6,15, or 16)
MBS.CONTROL.EventCmd_Processor
Data.DeviceDBAddress
0 to 9999
Modbus address of the target slave
database
MBS.CONTROL.EventCmd_Processor
Data.PointCount
0 to 125
Number of bit/words associated with this
command.
MBS.CONTROL.EventCmd_Processor
Data.Data[x]
0 to 49
Data values to be sent to the slave
MBS.CONTROL.EventCmd_Processor
Data.EventCmdStatusReturned
-
Command status
MBS.CONTROL.EventCmd_Processor
Data.PortxStatus
-
Port x Status array
MBS.CONTROL.EventCmd_Processor
Data.PortxStatus.Status
-
Status code. See Communication Error
Codes (page 100).
MBS.CONTROL.EventCmd_Processor
Data.PortxStatus.LastError
-
Last error code
