Pulsar SLUDGE FINDER 2 User Manual

Page 97
The third parameter for each relay determines the alarm ID for the relay you
wish to set.
P212, P222, P232, P242, P252, P262 - Relay Alarm ID
When P211, 221, 231, 241, 251, 261 = 3 (Loss of Echo), 4 (Loss of Clock), 5 (Wiper
Fault), 6 (Hi – Floc Alarm) or 7 (Service Interval Alarm)
This parameter has no function and will not be displayed.
P211, 221, 231, 241, 251, 261 = 1 (Level) or 2 (Temperature)
This parameter defines which alarm type the relay should respond to, as follows:
Alarm ID
Description
Setpoints
1=General (Default)
Relay goes “ON” when
the value reaches the ON
setpoint and goes “OFF”
when the value reaches
the OFF setpoint.
P213, 223, 233,
243, 253, 263 is
ON Setpoint;
P214, 224, 234,
244, 254, 264 is
OFF Setpoint.
2= High
Relay goes “ON” when
the value rises to the ON
setpoint and goes “OFF”
when the value lowers to
the OFF setpoint.
ON> OFF
Relay Setpoints
P213, 223, 233,
243, 253, 263 and
P214, 224, 234,
244, 254, 264
Setpoints, can be
set in any order as
the unit ‘knows’
that you are setting
a high level alarm.
3= Hi-Hi
Same as 2 = High, but
different identifier.
4= Low
Relay goes “ON” when
the value lowers to the
ON setpoint and goes
“OFF” when the value
rises to the OFF setpoint.
ON<OFF Relay
Setpoints
P213, 223, 233,
243, 253, 263 and
P214, 224, 234,
244, 254, 264.
Setpoints, can be
set in any order as
the unit ‘knows’
that you are setting
a low level alarm.
