Page 34
The systems supplied by Pulsar are ‘paired’ and care should be taken to ensure the
right Receiver is installed with the appropriate Transmitter if more than one system is
in operation on the same site.
The receiver unit should be pre set to 11 or greater, the transmitters are set to 1 or
greater, so for a transmitter address of, for example, 4 the receiver will be 14 and so
on. These are pre-set as the transmitter rotary dial are difficult to access.
Receiver Specifications
Max distance between Transmitter & Receiver with a clear line of sight is 3km.
Frequency. 2.4 GHz
Enclosure. Polycarbonate IP67, NEMA 6.
Power. 10-30vdc consumption less than 1.4W at 24VDC
Temp. (electronics) -20 to +80 C
