Pulsar SLUDGE FINDER 2 User Manual

Page 66
To program the unit for Example 1 Primary Settlement Sludge Interface
Monitoring, proceed as follows.
If required access the Program Mode.
Key in the passcode 1997 and press ENTER.
Use the arrow keys to scroll to the following menus and parameters and press
ENTER to access them. Select the relevant option using the up and down arrows
or type in the required value using the keypad and press ENTER to accept.
Menu
Sub Menu
Parameter
Value/Option
Application
Point 1
Mode P100
2 = Level
Xducer P101
7 = VT10
Material P102
2 = Primary
Tank Depth P115
2.8 (metres)
Xducer Depth P116
0.2 (metres)
Span P106
2.3 (metres)
Global
Measnt Units P104
1 = metres
Relays
Relay 1
Type P210
1 = Alarm
Function P211
1 = Level
Ident P212
2 = High
Setpoint 1 P213
1.95 (metres)
Setpoint 2 P214
1.85 (metres)
Allocation P216
1 = Xducer 1
All other parameters should remain at default values.
If combining the sludge interface monitoring with a tank liquid level monitor then
proceed to Example 1b Level Monitoring with Alarms on Point 2 otherwise,
programming is now complete and the unit can be returned to the run mode, press
CANCEL until Run Mode? Is displayed on the LCD press ENTER, and the
Sludge Finder 2 will return to the Run Mode.
