Pulsar SLUDGE FINDER 2 User Manual

Page 68
To program the unit for Example2 Level Monitoring with alarms, proceed as
follows.
If required access the Program Mode
Key in the passcode 1997 and press ENTER
Use the arrow keys to scroll to the following menus and parameters and press
ENTER to access them. Select the relevant option using the up and down arrows
or type in the required value using the keypad and press ENTER to accept.
Menu
Sub Menu
Parameter
Value/Option
Application
Point 2
Mode P1100
2 = Level
Xducer P1101
2 = dB6
Material P1102
1 = Liquid
Empty Level P1105
3.5 (metres)
Span P1106
2.8 (metres)
Relays
Relay 2
Type P220
1 = Alarm
Function P221
1 = Level
Ident P222
2 = High
Setpoint 1 P223
2.38 (metres)
Setpoint 2 P224
2.24 (metres)
Allocation P226
2 = Xducer 2
Relay 3
Type P230
1 = Alarm
Function P231
1 = Level
Ident P232
2 = Low
Setpoint 1 P233
0.28 (metres)
Setpoint 2 P234
0.42 (metres)
Allocation P236
2 = Xducer 2
mA Output
mAOut 2
Allocation P899
2 = Xducer 2
All other parameters should remain at default values.
Programming is now complete and the unit can be returned to the run mode, press
CANCEL until Run Mode? Is displayed on the LCD press ENTER, and the
Sludge Finder 2 will return to the Run Mode.
