BES X Dual Mode BES X Installation Manual, Rev.9, Jun 2018
148
148 P/N: 400288005
15.1 - Introduction
In this section, we will describe only the installation for the extra devices needed to interface the BES X
system with a Highway66, as the installation of the BES X units is similar to a standard scoring installation
and the connections between the different units are the same.
15.2 - Installation Layout
The 4HD/5HD-HUB unit has to be installed under the TMS chassis, in the support used for the chassis and
the 4HD-2COM unit has to be installed under the 4HD/5HD-HUB unit, as specified in the tables “T.90.262”
or “T.90.250”. Please refer to the table “T.90.251 – 4HD-2COM unit connections” for the connections for
the 4HD-2COM unit.
