QubicaAMF BES X User Manual

T. 0.01 60
JUN 20th 1820
286002861 SINGLE AND
286002863 SHORT SINGLE
PEDESTAL ASSEMBLY
PARTS
6
21
20
18 19
1
16
10
17
7
11
2
15
5
13
12
3
4
11
8
14
9
22
23
24
[8]
+0,8
0
3X ,31
+,03
- ,00
PRIOR TO ATTACHING
V-SUPPORT
11
3
DETAIL A
PARTS LIST
ITEM
1
2
QTY
1
1
1
P/N
286002802
286002806
DESCRIPTION
Base sheet metal - Lower
Base sheet metal - Higher
3
1
286002857
286002859
Console extrusion machined
Console extrusion short
4 1 286002866 V-Support single assembly
5
6
1
1
286002852
286002854
V-Support back
Front base cover
7
8
1
1
286002855
286002824
Rear base cover
Speaker wire harness single
9
10
1
1
770047105
741510403
Speaker
3/4" anti-short bushing
11 13 821805407 PHTTS ZN THFM TRIM5-,8 X 40
12
13
8
8
802408167
927158127
HHCS CL ZNM8-1,25 X 16 10,9
SWM ZNM8 D-127A
14
15
4
2
863040087
813005257
PHPMS ZNM4-,7 X 8
PHPMS ZNM5-,8 X 25
16
17
4
4
724520001
819304167
CON TPH ZNU M4-,7
FHPMS ZNM4-,7 X 16
18 5 951164007 SWM ANSI ZN3/8
19
20
9
5
948767132
810564420
FW ZN0,41 X 0,73 X 0,06
HHLB ZN3/8 X 2,00
21 5 709007063 ANCR TB ZN3/8 X 3,00
22
23
286002873
01033
Speaker plate
ETLW10 ANSI ZN
24 088500224 CBL, ground, wireway cover
1
1
