Accessories
R&S
®
TS7124M
46User Manual 1525.5394.02 ─ 05
Parameter Value
Gain -1 to 6 dBi (at 1.7 to 5 GHz)
6 to 10 dBi (at 5 to 20 GHz)
Max. input power 30 dBm (1 W)
Impedance 50 Ω
Polarization dual, cross-polarized linear (nom.)
Connectors 2x SMP (male)
Dimensions (W x D x H) 70 mm x 70 mm x 80 mm
This cross-polarized Vivaldi antenna with antenna fixture is not a serviceable part. If it
is defective, or if checking reveals that it is not working correctly, replace it.
See Chapter 8.3, "Checking", on page 153.
6.3.4 Narrowband antenna R&S TS-F24NB2
The narrowband bow-tie antenna R&S TS-F24NB2, order no. 1525.8793.02, with SMP
connector features excellent transmission properties in the frequency range from
0.7 GHz to 0.96 GHz. The antenna is based on a printed board with a structured metal
coating that spreads out in a bow-tie shape. The delivery includes an acrylic glass
sheet for mounting the antenna and an RF cable with SMP (female) and SMA (male)
connectors.
Antennas
