Figure 7-20: Detachable absorber pads re-installed at the chamber's rear wall
12. Optionally close the chamber's top cover (see Chapter 7.4.2, "Closing the top
cover", on page 80), especially if the half antenna ring will remain outside of the
chamber for an extended period of time.
7.6.2 Mounting the half antenna ring into the chamber
Start with the following:
●
The half antenna ring with antennas, configured as described in Chapter 7.10,
"Configuring Vivaldi antennas", on page 119
Figure 7-21: Antenna ring with some antennas mounted
Installing an antenna ring or holder
