CHAPTER
2
Manual No. 016-0171-362 Rev. F 5
CHAPTER 2
INTRODUCTION
The Raven ISOBUS single product control node is designed to add liquid or granular speed compensated product
control capabilities to ISOBUS virtual terminals. Adding the Raven ISOBUS product control node will allow a
machine operator to monitor and control a Raven product control system directly from a virtual terminal (VT)
display.
NOTE: Prior to using the product control feature with your VT display, the ISOBUS node must be calibrated
for the product control system. See Chapter 5, ISOBUS Product Control Operation, for more
information.
This manual assumes the required control hardware has already been installed on a specific
implement and is properly connected and wired.
RAVEN ISOBUS PRODUCT CONTROL NODE KITS
This section contains a list of kit contents which should have been supplied with the ISOBUS product control node.
Before installing the Raven ISOBUS node, compare the items in the kit with the list. If you have questions regarding
your kit, contact a local Raven dealer.
NOTE: A Raven ISOBUS hitch cable is required to connect the Raven ISOBUS product control node to the VT
display and ISOBUS system. Depending upon the specific machine, this cable may be installed from
the factory or must be ordered separately. Refer to Figure 1 on page 49 or contact a local Raven
dealer for more information.
TABLE 1. ISOBUS Single Product (Liquid/Granular) Node Kit
(16-Pin Product Cable) (P/N 117-6100-001)
NOTE: A 21’ spinner control cable (P/N 115-0171-880) is required if the ISOBUS product control system will be
utilized for spinner control applications.
TABLE 2.
Description Part Number Qty.
Terminator, Active CAN Powell 063-0172-964 1
Node, ISOBUS Single Product 063-0173-006 1
Switch, ISO Node Foot 063-0173-080 1
Cable, Main Node 115-0171-949 1
Cable, Cab Foot Switch, 8’ 115-0171-865 1
Cable, ISO Powell Terminator Adapter 115-0171-963 1
To Next Page
